620W Mono Crystalline Solar Panel - RENE SOLA
Nominal Maximun Power (Pmax) - 620W
Optimum Operating Voltage (Vmp) - 45.08V
Optimum Operating Current (Imp) - 13.76A
Open Circuit Voltage (Voc) - 54.39V
Short Circuit Current (Isc) - 14.52A
Maximum System Voltage - 1500V
Maximum Protection Current - 25A
Cell Type - Mono BC-type, 144(6x24)Half-cut cells
Number of Cells - 144 (6x24)
Weight - 27kg
Dimensions - 2278 x 1134 x 30mm
Glass - 3.2mm Tempered Coated Glass, Low Iron, High Transmission
Frame - Anodized Aluminium Alloy
Junction Box - Protection Degree IP68
Cable Thickness - 4.0mm
Cable Lenght - 300mm
Operating Temperature - -40℃~+85℃
Note： Information subject to product brochure, information may change or vary over time
